1/10 22X-4 4WD Buggy Race Kit

Introduction

Part # TLR03020

Features

• Shaft Drive Platform
• Fully Adjustable Suspension
• Premium Parts Included
• 2.5 Milled Aluminum Chassis
• G3 12mm Big Bore Shocks
• All New Gear Diffs
• Adjustable Inner Pivots
• Optimized Suspension Composites
• Elastomer Battery Mounting

• Floating Servo Mount
• Adjustable Motor and Battery Position
• Fresh 22X-4 Body Design
• Carbon Fiber Optimized
• All Metric Hardware
• TLR 6.5″ Rear Wing
• Easy Access Diffs
• Built-In Motor Fan Mount

In The Box

• (1) TLR 1/10 22X-4 Race Buggy Kit
• (1) Product Manual

Specifications:

• Type: Buggy Race Kit

• Scale: 1/10

• Length: 14″ (356mm)

• Width: 9.8″ (250mm)

• Height: 5.8″ (148mm)

• Wheelbase: 11.2″ (283.5mm)

• Chassis: 0.098″ (2.5mm) thick 7075-T6 milled aluminum plate

• Suspension: Lower A-arm, upper adjustable link, Stiffezel front and rear arms

• Drivetrain: 4WD Shaft Drive

• Gear Pitch: 48-pitch

• Wheel Size: 2.2″ (56mm)

• Kit/RTR: Kit

• Shock Type: Oil-filled 12mm Big Bore

• Body: 22X-4, 0.7mm thick lightweight

• Ball Bearings: Full set, rubber sealed

• Is Assembly Required: Yes

Needed to Complete

• (1) Transmitter and Receiver
• (1) Steering Servo
• (1) Steering Servo Mount (TLR331036 Recommended)
• (1) 2S LiPo or LiHV Battery
• (1) Compatible Battery Charger
• (1) 48P Pinion Gear
• (1) Motor
• (1) ESC
• (1) Tire Glue
• (4) Tires
• Polycarbonate Paint
• Tools (Please reference the manual for more details)
